Solid Lubricant Manganese Bronze Sliding Bearings Flanged Plate CuZn25AI5Mn4 C86300

Brand Name : bronzelube.com

Model Number : Straight Bushing:Bronze with Embedded Solid Lubricant Material,Lead Free

Certification : Plain Sleeve Bearings Standards met: RoHS

Place of Origin : Self Lube Bearings

MOQ : Bronze Precision Wear Plates & Lubricating Parts made to order

Price : US$0.11 - US$21.11 / Pieces,NEGOTIABLE

Payment Terms : TT IN ADVANCE,L/C,Western Union

Supply Ability : Self Lube Bearing Manufacturing Dimensions Tolerance Assembly

Delivery Time : Shipped in 3-20 work days

Packaging Details : Cartons with good information lable

Material : Aluminum-Bronze With Solid Lubricant

Types : Silde Block

Description : Solid Lubricating Bearings

Application : Mediate Load But Higher Temperature And Condition With Mediate Running Velocity Etc.

Size : standard,Drawings

Shape : Plate

Production Feature : Casting

Matrrial : CuZn25AI5Mn4Fe3

Bearing Bushing Factory Price : tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer : https://www.viiplus.com/

High Light : Bronze Wear Plates , Self Lubricating - Special Brass Alloy

Self Lubricating Graphite Plugged Bronze Plate : Bronze Wear Plate and Pad for Industrial Machinery, manufacturer of bronze sleeve bushings, we often receive requests for a variety of product types.

Bush Bearings Manufacturers Suppliers Exporters : plain bearings. Long, maintenance-free service, manufactures bushings in various designs and from different materials. tiffany@viiplus.com, Bushings - Configure and purchase - https://www.viiplus.com/

Contact Now

Solid Lubricant Manganese Bronze Sliding Bearings with Flanged Plate, made of CuZn25Al5Mn4 (C86300), are designed to provide smooth and reliable sliding motion under various conditions. The manganese bronze alloy CuZn25Al5Mn4 possesses excellent wear resistance, strength, and ductility, which are critical properties for sliding bearings.

The incorporation of solid lubricants within the manganese bronze material helps to further reduce friction and wear during sliding. These solid lubricants are dispersed throughout the material matrix, providing a continuous lubricating film that minimizes the need for external lubrication.

The flanged plate design of these sliding bearings provides additional stability and support, ensuring proper alignment and positioning during operation. This design also helps to distribute the load evenly across the bearing surface, further enhancing its durability and performance.

Overall, Solid Lubricant Manganese Bronze Sliding Bearings with Flanged Plate, CuZn25Al5Mn4 (C86300), are an excellent choice for applications requiring smooth sliding motion, high wear resistance, and reduced maintenance.

CuZn25AI5Mn4 C86300 Solid Lubricant Cast High Tensile Self lubricating bearing FLANGED PLATE | VSB-50P

Bronze Cast Alloys C86200 Manganese Bronzes C86200 Cast Manganese Bronze INCH SIZES | VSB-50P

Sliding Bearing
VIIPLUS constantly study new materials and new products development

VIIPLUS International is a professional manufacturer of plain bearings and wear plates, and has grown rapidly to a point where now all types of plain bearings can be supplied. Standard catalogue sizes, special sizes and designs can be produced at competitive prices and to a high quality standard. VIIPLUS serves both the domestic and international markets. The VIIPLUS international intend to stay at the forfront of this market.

Manganese Bronze Sliding Bearings Product Features

1．No oil supply device, oil hole, oil groove
The cost of the fuel supply system, the cost of processing, assembling, and so on, can greatly reduce the cost of manufacturing.

2．Operation cost reduction
Greatly reduce the use of lubricating oil and equipment maintenance costs, but also exempt from the risk caused by the shortage of oil.

3．Design time shortened
No oil can make the design, structure is greatly simplified, reduce costs, save design time. In addition, using self-lubricating bearings can also improve the mechanical properties and prolong get remarkable results using life and improve the reliability.

4．Recovery and environmental protection of lubricant
No need to waste oil recycling, is conducive to environmental protection.

Chemical Requirements
Copper Alloy UNS No.	Composition, % max, except as indicated
						Nickel
	Copper	Tin	Lead	Zinc	Iron	Including	Aluminum	Manganese	Antimony	Sulfur	Phosphorus	Silicon
						Cobalt
C86300	60.0–66.0	0.20	0.20	22.0–28.0	2.0–4.0	1.0A	5.0–7.5	2.5–5.0	...	...	...	...
C90500	86.0–89.0	9.0–11.0	0.30	1.0–3.0	0.20	1.0A	0.005	...	0.20	0.05	0.05B	0.005
C91100	82.0–85.0	15.0–17.0	0.25	0.25	0.25	0.50A	0.005	...	0.20	0.05	1.0B	0.005
C91300	79.0–82.0	18.0–20.0	0.25	0.25	0.25	0.50A	0.005	...	0.20	0.05	1.0B	0.005
C93700	78.0–82.0	9.0–11.0	8.0–11.0	0.8	0.7C	0.50A	0.005	...	0.50	0.08	0.10B	0.005
A In determining copper minimum, copper may be calculated as copper plus nickel.
B For continuous castings, phosphorus shall be 1.5 % max.
C Iron shall be 0.35 % max. when used for steel-backed.

Self lubricating flange bearings in extra durable bronze.

Material:

CuZn25AI5Mn4Fe3 + graphite

– Maintenance-free (self-lubricating)
– Suitable for heavy load applications
– Withstands extreme temperatures
– Long life span

1 Areas of use
Hardware and steel fabrication, stamping
dies, tooling components for the
automotive industry, sheet pressing etc.

2 Shapes & forms
Guide bushings, clamps, half bearings,
wear plates, washers, guide plates etc.

VIIPLUS Bronze GLEITLAGER offers C86200 Manganese Bronze as Made to Order Castings. Self Lubricating Bronze Wear Plate

This material is used in a variety of applications. Typical uses for this alloy are: Marine castings, gears, gun mounts, bushings and bearings.

3 Types of Bushings

Sleeve Bearing, Flange Bearing & Thrust Bearing. Each type is available as a Plain, Oil or Grease Grooved and Graphite Plugged.

CHARACTERISTICS

VSB-50P Sliding Block olid Bronze Metallic Self-lubricating Bearings

Solid Lubricant Cast Bronze Bearings Silde Block With Immediate Running Velocity

Metric Bronze Bushings Block Tin-Bronze For Metallurgy / Drying Machine

Cast Bronze Bearing with Graphite Plugs

VSB-50P Sliding Block

Copper Cast Bronze Bearings Slide Block Anti Abrasion For Transportation Machines

1. May work without any ol for long period

2. Extremely high load capacity, good anti-wear and lower friction

3. Particularly appropriate for low speed and high load

4. Suitable for reciprocating, oscillation or intermittent motion where oil film is hard to be formed

5. Good chemical resistant and anti-corrosion characteristics

6. Can be used in wide range of temperature from -40℃-+300℃

Aluminum-Bronze With Solid Lubricant Casting Bronze Silde Block

Aluminum-Bronze Solid Lubricating Silde Block is backed with Aluminum-Bronze alloy with good capability of mechanics, castings and anti-erosion. The surface of Aluminum-Bronze Solid Lubricating Silde Block is regularly and finely machined with sockets in which particular solid lubricant is filled.

Aluminum-Bronze Solid Lubricating Silde Block is widely used conditions with mediate load but higher temperature and condition with mediate running velocity etc.

The surface of Aluminum-Bronze Solid Lubricating Silde Block is regularly and finely machined with sockets in which particular solid lubricant is filled.

STRUSTURE

VSB-50P Sliding Block material is made of strong cast bronze based metal with special solid lubricants embedded. The base metal withstands high load and the solid lubricants provide self-lubrication. The bearing shows excellent performance without pre-lubrication under conditions of extreme high/low temperature with low speed. This material provides a maintenance-free bearing solution, particularly for high load, intermittent of oscillating motion.

TECHNICAL DATA

Grade	50#	50S1	50S2	50S3	650S5
Material	CuZn25AI5Mn4Fe3	CuSn5Pb5Zn5	CuAI10Ni5Fe5	CuSn12	CuZn25AI5Mn4Fe3
Density	8	8.9	7.8	8.9	8
Hardness	≥210	≥70	≥150	≥75	≥235
Tensile strength	≥750	≥250	≥500	≥270	≥800
Yield strength	≥450	≥90	≥260	≥150	≥450
Elongation	≥12	≥13	≥10	≥5	≥8
Coefficient o linear expansion	1.9×10-5/℃	1.8×10-5/℃	1.6×10-5/℃	1.8×10-5/℃	1.9×10-5/℃
Max.Temp.	-40~+300℃	-40~+400℃	-40~+400℃	-40~+400℃	-40~+300℃
Max.dynamic load	100	60	50	70	120
Max.speed(Dry)	15	10	20	10	15
N/mm²*m/s(Lubrication)	200	60	60	80	200
Compression deformation	< 0.01 mm	< 0.05mm	< 0.04mm	< 0.05mm	< 0.005mm

Chemical Compositions

Product NO.	Chemical Compositions
VSB-50	Cu	Zn	Al	Fe	Mn	Si	Ni	Sn	Pb
VSB-50	60~66	22~28	5.0~8.0	2.0~4.0	2.5~5.0	<0.1	<0.5	<0.2	<0.2

AVAILABILITY

Bearing forms available in standard dimensions

· Cylindrical bushes
· Flanged bushes
· Sliding plates

Bearing forms made to order: standard forms in special dimensions, thrust washers, flanged thrust washers, half-bearings, special shapes obtained by stamping or deep drawing, customized bearing designs

TYPICAL APPLICATIONS

This kind of bearing can be applied under dry, high temperature, high pressure, corrosive, water or other chemical environments when no oil can be introduced. It is widely used in automotive products line, water engineering, dam gate, plastic industries, successive casting machines, steel rollers in metallurgy industry, mineral machines, ships, turbo generators, hydraulic turbines and injection molding machines...

Solid Lubricant Manganese Bronze Sliding Bearings Flanged Plate CuZn25AI5Mn4 C86300

Solid Bronze Metallic Self-lubricating CUSTOMER SIZE Dimensions and Tolerances

START YOUR
PROJECTWITH AN APPLICATION ENGINEER

thrust washer&plate inch size
